Air Curtain

.1209X2Y CROSSFLOW

SRP 5,899.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 36 inches length
• 150 watts input power
• 1200 air volume (m³/h)
•  ≤43 Noise (db)
• 13kg weight
• With remote control

Product Dimension
    900x215x200 (mm)

.1210X2Y CROSSFLOW

SRP 6,299.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 40 inches length
• 150 watts input power
• 1350 air volume (m³/h)
•  ≤43 Noise (db)
• 14.50kg weight
• With remote control

Product Dimension
    1000x215x200 (mm)

.1212X2Y CROSSFLOW

SRP 6,999.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 48 inches length
• 180 watts input power
• 1700 air volume (m³/h)
•  ≤44 Noise (db)
• 17kg weight
• With remote control

Product Dimension
    1200x215x200 (mm)

.1215X2Y CROSSFLOW

SRP 8,899.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 59 inches length
• 220 watts input power
• 2100 air volume (m³/h)
•  ≤46 Noise (db)
• 21kg weight
• With remote control

Product Dimension
    1500x220x200 (mm)

1209X2 CROSSFLOW

SRP 5,299.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 36 inches length
• 150watts input power
• 1200 air volume (m³/h)
•  ≤43 Noise (db)
• 13kg weight

Product Dimension
    900x215x200 (mm)

1210X2 CROSSFLOW

SRP 5,799.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 40 inches length
• 150watts input power
• 1350 air volume (m³/h)
•  ≤43 Noise (db)
• 14.5 kg weight

Product Dimension
    1000x215x200 (mm)

1212X2 CROSSFLOW

SRP 6,499.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal maintenance
• Easy installation and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 48 inches length
• 180 watts input power
• 1700 air volume (m³/h)
• ≤44 Noise (db)
• 17kg weight

Product Dimension
1200x215x200 (mm)

1215X2 CROSSFLOW

SRP 8,299.00

Product Specifications

• Slim all metal housing with aesthetic curve design
• Full metal shell and minimal  maintenance
• Easy installation  and cleaning
• Air velocity 11.0 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 2.3-3 meters
• Single motor design for lower installation requirements
• 59 inches length
• 220 watts input power
• 2100 air volume (m³/h)
•  ≤46 Noise (db)
• 21kg weight

Product Dimension
    1500x220x200 (mm)

3515SL S-L Centrifugal

SRP 11,399.00

Product Specifications

• Full metal housing with unique design
• Centrifugal style fan
• Uniform forced air flow
• Air speed greater than 14.5 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 3-4 meters
• Twin motor design for higher installation requirements
• 59 inches length
• 330 watts input power
• 1700 air volume (m³/h)
• ≤48 Noise (db)
• 25kg weight

Product Dimension
1500x230x212 (mm)

35092SL S-L Centrifugal

SRP 7,599.00

Product Specifications

• Full metal housing with unique design
• Centrifugal style fan
• Uniform forced air flow
• Air speed greater than 14.5 m/s
• Voltage / frequency 220V 60HZ
• 120mm diameter of wheel
• Installation height 3-4 meters
• Twin motor design for higher installation requirements
• 36 inches length
• 220 watts input power
• 1020 air volume (m³/h)
• ≤44 Noise (db)
• 17kg weight

Product Dimension
900x230x212 (mm)
