Product Specifications
HVLS MOBILE INDUSTRIAL DRUM FAN
• 0.75m grille diameter
• 3 fan blades
• With automatic vertical louver oscillation
• 21,000 m3/h airflow
• 200watts Asynchronous speed regulating motor
• 3 fan speed setting
• 900r/min maximum speed
Dimensions: (L)820 x (W)330 x (H)945 mm
Product Specifications
HVLS MOBILE INDUSTRIAL PMSM DRUM FAN
• 0.88m grille diameter
• 5 fan blades
• With automatic vertical louver oscillation
• 26,000 m3/h airflow
• 500watts permanent magnet synchronous motor
• With variable speed
• 900r/min maximum speed
• 35-40m air supplying distance
• 24kgs net weight
Dimensions: (L)950 x (W)470 x (H)1100 mm
Product Specifications
HVLS MOBILE INDUSTRIAL PMSM DRUM FAN
• 1.175m grille diameter
• 6 fan blades
• 30,000 m3/h airflow
• 500watts permanent magnet synchronous motor
• With variable speed
• 500r/min maximum speed
• 33kgs net weight
Dimensions: (L)1300 x (W)550 x (H)1430 mm
Product Specifications
HVLS MOBILE INDUSTRIAL PMSM DRUM FAN
• 6 fan blades
• 42,000 m3/h airflow
• 600watts permanent magnet synchronous motor
• With grab handles for convenient transport
• With auto swing/oscillation function
• With variable speed
• 480r/min maximum speed
• 58kgs net weight
Dimensions: (L)1570 x (W)760 x (H)1780mm
Product Specifications
HVLS MOBILE INDUSTRIAL PMSM DRUM FAN
• 1.98m grille diameter
• 3 fan blades
• 90,000 m3/h airflow
• 1800watts permanent magnet synchronous motor
• With variable speed
• 420r/min maximum speed
• 35-40m air supplying distance
• 78kgs net weight
Dimensions: (L)2160 x (W)800 x (H)2315 mm
Product Specifications
• 30″ Industrial PMSM Drum Fan
• 400watts Permanent Magnet Series Motor (PMSM)
for higher efficiency and longer lifespan
• VFD Stepless speed knob switch control
(from Breeze to Gale & then Storm wind settings)
• 950rpm max speed
• 35m air throw distance
• 25,000 m3/h air volume
• 200-300sqm coverage area
• With heavy duty caster wheels for easy transport
• 21kg net weight
Dimensions:
(L)920 x (W)470 x (H)1070 mm
Product Specifications
HVLS MOBILE INDUSTRIAL PMSM DRUM FAN
• 600watts permanent magnet synchronous motor
• With variable speed
• 1.5 meters fan diameter
• 42,000 m3/min airflow
• 480r/min maximum speed
• 35-40m air supplying distance
• 58kgs net weight
• 400-500m2 usable area
Dimensions: (L)1570 x (W)760 x (H)1690mm
Product Specifications
HVLS MOBILE INDUSTRIAL PMSM DRUM FAN
• 1,100watts permanent magnet synchronous motor
• With variable speed
• 2.0 meters fan diameter
• 56,000 m3/min airflow
• 200-480r/min maximum speed
• 35-40m air supplying distance
• 67kgs net weight
• 400-500m2 usable area
Dimensions: (L)1800 x (W)800 x (H)2000mm
Product Specifications
• 28″ Industrial drum fan
• 320 watts power
• 320 PMSM motor power
• 12,000 m/h airflow
• ≤50 dB noise level
• 1-15 speed setting
• 24kg weight
Dimensions: (L)800 x (W)520 x (H)1080 mm
Product Specifications
• 28″ Industrial drum fan
• 320 watts power
• 320 PMSM motor power
• 12,000 m/h airflow
• ≤50 dB noise level
• 1-15 speed setting
• With auto swing/oscillation function
• 25.5kg weight
Dimensions: (L)800 x (W)520 x (H)1080 mm
Product Specifications
• 32″ Industrial drum fan
• 420 watts power
• 420 PMSM motor power
• 18,000 m/h airflow
• ≤55 dB noise level
• 1-15 speed setting
• 28kg weight
Dimensions: (L)980 x (W)580 x (H)1200 mm
Product Specifications
• 32″ Industrial drum fan
• 420 watts power
• 420 PMSM motor power
• 18,000 m/h airflow
• ≤55 dB noise level
• 1-15 speed setting
• With auto swing/oscillation function
• 29kg weight
Dimensions: (L)980 x (W)580 x (H)1200 mm
Product Specifications
• 36″ Industrial drum fan
• 500 watts power
• 500 PMSM motor power
• 22,000 m/h airflow
• ≤45 dB noise level
• 1-15 speed setting
• 30kg weight
Dimensions: (L)1080 x (W)580 x (H)1270 mm
Product Specifications
• 36″ Industrial drum fan
• 500 watts power
• 500 PMSM motor power
• 22,000 m/h airflow
• ≤45 dB noise level
• 1-15 speed setting
• With auto swing/oscillation function
• 31.5kg weight
Dimensions: (L)1080 x (W)580 x (H)1270 mm
Product Specifications
• 44 inches diameter industrial HVLS mobile drum fan
• 4 pcs. heavy duty & omni-directional 4” wheels with lock
• Patented blade design for large area and stable air volume
• Speed control switch
• With grab handles for convenient transport
• 500 watts power
• 480 max rpm
• 20,000 m³/hour airflow
• 50dB noise level
• 44kg net weight
Dimensions:
(L)1320 x (W)720 x (H)1460 mm
Product Specifications
• 52 inches diameter industrial HVLS mobile drum fan
• 4 pcs. heavy duty & omni-directional 6” wheels with lock
• Patented blade design for large area and stable air volume
• Speed control switch
• With grab handles for convenient transport
• 600 watts power
• 440 max rpm
• 38,000 m³/hour airflow
• 55dB noise level
• 58kg net weight
Dimensions:
(L)1540 x (W)785 x (H)1670 mm
Product Specifications
• 48 inches diameter industrial HVLS mobile drum fan
• Full metal frame build
• 4 pcs. heavy duty & omni-directional wheels with lock
• Patented blade design for large area and stable air volume
• PMSM motor
• VFD STEPLESS SPEED control switch
• With grab handles for convenient transport
• 600 watts power
• 40-45 meters airflow distance
• 440 max rpm
• 38,000 m³/hour airflow
• 400-500 sqm. coverage area
• 60kg net weight
Dimensions: (L)1500 x (W)790 x (H)1650 mm
