HVLS (CEILING) INDUSTRIAL FANS

TORNADO HVLS-8X

SRP 99,995.00

Product Specifications
new2

• 8ft. Industrial Ceiling Fan
• High efficiency and energy-saving motor.
• Dust proof structure and long service life motor
• High strength, lightweight impact-resistant & with long service life, large air volume
& high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and
energy-saving while ventilating a large area of coverage.
• Control Box – with status display, Ambient temperature display,
soft touch wind speed control and power control panel.
• Suitable for large logistics warehouses, distribution centers,
large workshop, public buildings, large farms and etc.

Technical:
• 150 watts power
• 8.2 feet fan diameter
• 120rpm speed
• 3,600m3/min air volume
• 48Hz frequency
• 39dB(A) noise
• 225m2 wind coverage area
• 56m2 wind speed ≥ 1 m/s
• 40.5kg fan body weight
(Motor + Blade + connecting square tube)



TORNADO HVLS-10X

SRP 119,995.00

Product Specifications

new2
• 10ft. Industrial Ceiling Fan
• High efficiency and energy-saving motor.
• Dust proof structure and long service life motor
• High strength, lightweight impact-resistant & with long service life, large air volume
& high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and
energy-saving while ventilating a large area of coverage.
• Control Box – with status display, Ambient temperature display,
soft touch wind speed control and power control panel.
• Suitable for large logistics warehouses, distribution centers,
large workshop, public buildings, large farms and etc.

Technical:
• 260 watts power
• 9.84 feet fan diameter
• 110rpm speed
• 5,250m3/min air volume
• 44Hz frequency
• 39dB(A) noise
• 330m2 wind coverage area
• 115m2 wind speed ≥ 1 m/s
• 43kg fan body weight
(Motor + Blade + connecting square tube)





TORNADO HVLS-12X

SRP 129,995.00

Product Specifications
new2

• 12ft. Industrial Ceiling Fan
• High efficiency and energy-saving motor.
• Dust proof structure and long service life motor
• High strength, lightweight impact-resistant & with long service life, large air volume
& high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and
energy-saving while ventilating a large area of coverage.
• Control Box – with status display, Ambient temperature display,
soft touch wind speed control and power control panel.
• Suitable for large logistics warehouses, distribution centers,
large workshop, public buildings, large farms and etc.

Technical:
• 325 watts power
• 11.81 feet fan diameter
• 85rpm speed
• 5,850m3/min air volume
• 34Hz frequency
• 39dB(A) noise
• 425m2 wind coverage area
• 165m2 wind speed ≥ 1 m/s
• 46kg fan body weight
(Motor + Blade + connecting square tube)



TORNADO HVLS-5

SRP 49,500.00

Product Specifications
new2

• 5ft. Industrial Ceiling Fan
• High efficiency and energy-saving motor.
• Dust proof structure and long service life motor
• High strength, lightweight impact-resistant & with long service life, large air volume
& high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and
energy-saving while ventilating a large area of coverage.
• Control Box – with status display, Ambient temperature display,
soft touch wind speed control and power control panel.
• Suitable for large logistics warehouses, distribution centers,
large workshop, public buildings, large farms and etc.

Technical:
• 110 watts power
• 1.52m (5feet) fan diameter
• 300 rpm max speed
• 1,100m3/min air volume
• 16.75kg weight



TORNADO HVLS-6

SRP 59,500.00

Product Specifications

new2
• 6ft. Industrial Ceiling Fan
• High efficiency and energy-saving motor.
• Dust proof structure and long service life motor
• High strength, lightweight impact-resistant & with long service life, large air volume
& high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and
energy-saving while ventilating a large area of coverage.
• Control Box – with status display, Ambient temperature display,
soft touch wind speed control and power control panel.
• Suitable for large logistics warehouses, distribution centers,
large workshop, public buildings, large farms and etc.

Technical:

• 150 watts power
• 1.82m (6feet) fan diameter
• 250 rpm max speed
• 1,800m3/min air volume
• 17.35kg weight

TORNADO HVLS-7

SRP 69,500.00

Product Specifications

new2
• 7ft. Industrial Ceiling Fan
• High efficiency and energy-saving motor.
• Dust proof structure and long service life motor
• High strength, lightweight impact-resistant & with long service life, large air volume
& high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and
energy-saving while ventilating a large area of coverage.
• Control Box – with status display, Ambient temperature display,
soft touch wind speed control and power control panel.
• Suitable for large logistics warehouses, distribution centers,
large workshop, public buildings, large farms and etc.

Technical:

• 220 watts power
• 2.1m (6.88feet) fan diameter
• 200 rpm max speed
• 2,500m3/min air volume
• 13kg weight

Available Color: White and Black

TORNADO HVLS-8

SRP 179,900.00

Product Specifications
new2

• 8ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 150 watts power
• 2,440mm (8feet) fan diameter
• 125rpm speed
• 4,500m3/min air volume
• 39db(A) Noise
• 240sqm. wind coverage area
• 4,000mm distance from ground
• 77kg weight of whole fan set (motor, blade & tube)
• 8kg weight of control box



TORNADO HVLS-9

SRP 189,900.00

Product Specifications

new2
• 9ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 180 watts power
• 2,740mm (9feet) fan diameter
• 120rpm speed
• 5,000m3/min air volume
• 39db(A) Noise
• 280sqm. wind coverage area
• 4,000mm distance from ground
• 78.5kg weight of whole fan set (motor, blade & tube)
• 8kg weight of control box

TORNADO HVLS-10

SRP 199,900.00

Product Specifications

new2
• 10ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 220 watts power
• 3,040mm (10feet) fan diameter
• 110rpm speed
• 5,600m3/min air volume
• 39db(A) Noise
• 350sqm. wind coverage area
• 4,000mm distance from ground
• 80kg weight of whole fan set (motor, blade & tube)
• 8kg weight of control box

TORNADO HVLS-12

SRP 209,900.00

Product Specifications
new2

• 12ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 320 watts power
• 3,650mm (12feet) fan diameter
• 100rpm speed
• 6,600m3/min air volume
• 39db(A) Noise
• 450sqm. wind coverage area
• 4,000mm distance from ground
• 83kg weight of whole fan set (motor, blade & tube)
• 8kg weight of control box



TORNADO HVLS-14

SRP 229,900.00

Product Specifications
new2

• 14ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 480 watts power
• 4,260mm (14feet) fan diameter
• 90rpm speed
• 8,500m3/min air volume
• 39db(A) Noise
• 610sqm. wind coverage area
• 4,000mm distance from ground
• 84.2kg weight of whole fan set (motor, blade & tube)
• 8kg weight of control box

TORNADO HVLS-16

SRP 249,900.00

Product Specifications
new2

• 16ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 720 watts power
• 4,870mm (16feet) fan diameter
• 85rpm speed
• 10,500m3/min air volume
• 39db(A) Noise
• 700sqm. wind coverage area
• 4,000mm distance from ground
• 89.7kg weight of whole fan set (motor, blade & tube)
• 8kg weight of control box



TORNADO HVLS-18

SRP 259,900.00

Product Specifications
new2

• 18ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.
Technical:
• 850 watts power
• 5,500mm (18feet) fan diameter
• 80rpm speed
• 12,000m3/min air volume
• 39db(A) Noise
• 800sqm. wind coverage area
• 4,000mm distance from ground
• 96.65kg weight of whole fan set (motor, blade & tube)
• 4.4kg weight of control box





TORNADO HVLS-21

SRP 269,900.00

Product Specifications

new2
• 21ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.
Technical:
• 1,150 watts power
• 6,500mm (21feet) fan diameter
• 70rpm speed
• 14,800m3/min air volume
• 39db(A) Noise
• 1,000sqm. wind coverage area
• 4,000mm distance from ground
• 101.55kg weight of whole fan set (motor, blade & tube)
• 4.4kg weight of control box





TORNADO HVLS-24

SRP 279,900.00

Product Specifications
new2

• 24ft. Industrial Ceiling Fan
• High efficiency and energy-saving rotor motor.
• Dust proof structure and long service life motor
• Blade is made of aviation polymer composite material (helicopter wing materials).
• High strength, lightweight impact-resistant, anti-aging & with long service life, large air volume & high pressure airflow, Highly efficient & energy-saving ventilation product.
• Omni-directional natural wind – High efficiency and energy-saving while ventilating a large area of coverage.
• Control Box – with customized frequency converter over current protection, over-voltage, protection, under-voltage protection and overload protection
• Suitable for large logistics warehouses, distribution centers, large workshop, public buildings, large farms and etc.

Technical:
• 1,280 watts power
• 7,300mm (24feet) fan diameter
• 60rpm speed
• 17,500m3/min air volume
• 39db(A) Noise
• 1,250sqm. wind coverage area
• 4,500mm distance from ground
• 105.55kg weight of whole fan set (motor, blade & tube)
• 4.4kg weight of control box
